Revolution Performance Big Bore Kits??

Revolution Performance uses a big bore kit that has all aluminum cylinders with "nickel silicon carbide" plating. The say it's stronger than cast iron and lasts three to four times longer. Has anyone ever installed one of their kits? If so, what are your thoughts, good or bad.

Nevadasun
Nevadasun is offline
Sponsored Links
Advertisement

post #2 of 11 (permalink) Old 02-11-2013, 01:32 AM
Member

spokanebagfan's Avatar

Join Date: Mar 2012
Location: Spokane Washington
Posts: 569
Talk to frank at dragos he does quite a few of them.
spokanebagfan is offline
post #3 of 11 (permalink) Old 02-11-2013, 07:14 AM
Grey beard

Join Date: Oct 2011
Location: Munnsville,N.Y.
Posts: 1,432
Quote:
Originally Posted by Nevadasun View Post
Revolution Performance uses a big bore kit that has all aluminum cylinders with "nickel silicon carbide" plating. The say it's stronger than cast iron and lasts three to four times longer. Has anyone ever installed one of their kits? If so, what are your thoughts, good or bad.

Nevadasun
We bore the cast-iron lined OEM cylinder to 107", and have since 2007.
Never an issue.
Scott
Hillsidecycle.com is offline

post #4 of 11 (permalink) Old 02-11-2013, 07:23 AM
Administrator

dbell66253's Avatar

Join Date: Feb 2011
Location: South Florida
Posts: 12,284
Garage
I have the Rev Performance 107, love it. They have a video somewhere on You Tube that shows their cylinders next to an OEM bored cylinder. BTW I haven't heard of anybody having problems with bored OEM cylinders either.

2010 FLTRX With Plenty of extras, goes by the name "Hardeshia"
To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.
Also not pictured 2016 FLTRXS and 2017 FLTRXS, you never can have too many SHARKS......

Last edited by dbell66253; 02-12-2013 at 07:32 AM.
dbell66253 is offline
post #5 of 11 (permalink) Old 02-11-2013, 07:33 AM
prodrag1320
Guest

Posts: n/a
too many problems with the nikasill coming off,I prefer to bore HD cylinders to 107"

Last edited by prodrag1320; 02-11-2013 at 07:36 AM.
post #6 of 11 (permalink) Old 02-11-2013, 08:53 AM
Life Member

Join Date: Nov 2010
Location: 4977 Torque Rd Loves Park ILL, 61111
Posts: 1,910
This is the same old thing you see. I have been using REV PEF 107 cylinders for over 6 years and never had an issue we check and file fit rings and clean them up before install. Fastbagger 09 has them on his bike since 2009 with 210 plus hp never had an issue he beats the shit out of that bike. I feel sorry for that bike.

Yes they had an issue in the past and it was not the Nickasi from what I have seenl. It is very hard to cut Nickasil.

The rings were the problem I seen it first hand on 2006 stglide with there REV PER 124 kit. Another shop built the bike and then I re-did it for him and the bike makes 142 hp 148 tq. to this day no issues he just had it at Sturgis last year.
I my self have never seen the Nickasil flake off. Not to say it has not. But we work on many different bikes here from Metric to US and have never seen that.

Its the old saying some people had some bad experience with them I can understand the bad taste in there month's and never want to use them again.

Again we have seen stock cylinders go bad just as fast and crack spigots. etc.,

Not here to fight with anyone just what I see here...

Here is ATTCH of a Spigot on a 107
Here Is ATT of a Spigot on a 88/96" Avg give or take

Sorry I dont have one here of a Stock 103 to show





Quote:
Originally Posted by Nevadasun View Post
Revolution Performance uses a big bore kit that has all aluminum cylinders with "nickel silicon carbide" plating. The say it's stronger than cast iron and lasts three to four times longer. Has anyone ever installed one of their kits? If so, what are your thoughts, good or bad.

Nevadasun
Attached Images
File Type: jpg stock 107 spigot thick..jpg (84.4 KB, 84 views)
File Type: jpg Stock spigot on harley 96 inch.jpg (86.2 KB, 69 views)

Last edited by DragoBikeWorks; 02-11-2013 at 09:05 AM.
DragoBikeWorks is offline
post #7 of 11 (permalink) Old 02-11-2013, 09:21 AM
Grey beard

mocotom's Avatar

Join Date: May 2012
Location: Pa
Posts: 1,110
I have used the Revperf Nikasil kits a few times with excellent results, but have used 10 times that many bored stock cylinders also without problems. I stay away from the very large high comp. builds, so any advantage in cylinder strength is not a major concern to me. I do think the nikasil kits run cooler.


To view links or images in signatures your post count must be 10 or greater. You currently have 0 posts.

2005 RG 98cu in
USMC 1968-1972
mocotom is offline
post #8 of 11 (permalink) Old 02-11-2013, 09:22 AM Thread Starter
Grey beard

Nevadasun's Avatar

Join Date: Dec 2010
Location: Las Vegas,NV
Posts: 932
Garage
Quote:
Originally Posted by DragoBikeWorks View Post
This is the same old thing you see. I have been using REV PEF 107 cylinders for over 6 years and never had an issue we check and file fit rings and clean them up before install. Fastbagger 09 has them on his bike since 2009 with 210 plus hp never had an issue he beats the shit out of that bike. I feel sorry for that bike.

Yes they had an issue in the past and it was not the Nickasi from what I have seenl. It is very hard to cut Nickasil.

The rings were the problem I seen it first hand on 2006 stglide with there REV PER 124 kit. Another shop built the bike and then I re-did it for him and the bike makes 142 hp 148 tq. to this day no issues he just had it at Sturgis last year.
I my self have never seen the Nickasil flake off. Not to say it has not. But we work on many different bikes here from Metric to US and have never seen that.

Its the old saying some people had some bad experience with them I can understand the bad taste in there month's and never want to use them again.

Again we have seen stock cylinders go bad just as fast and crack spigots. etc.,

Not here to fight with anyone just what I see here...

Here is ATTCH of a Spigot on a 107
Here Is ATT of a Spigot on a 88/96" Avg give or take

Sorry I dont have one here of a Stock 103 to show
I would like to go with something more than a 107. Revolution Performance now offers a 113 kit with 10.5:1 pistons. This setup seems to be more of what I'm looking for, don't really need whiplash when I roll-on. However, I am looking for more power with a setup that will last over the years. I don't beat the crap out of that bike, and I won't even with more power.

Nevadasun

Nevadasun is offline
post #9 of 11 (permalink) Old 02-11-2013, 10:53 AM
prodrag1320
Guest

Posts: n/a
if theve truelly over come their problems,by all means use them.I still prefer to bore HD cylinders to 3.935,
post #10 of 11 (permalink) Old 02-12-2013, 06:49 AM
Grey beard

Join Date: Oct 2011
Location: Munnsville,N.Y.
Posts: 1,432
Quote:
Originally Posted by Nevadasun View Post
I would like to go with something more than a 107. Revolution Performance now offers a 113 kit with 10.5:1 pistons. This setup seems to be more of what I'm looking for, don't really need whiplash when I roll-on. However, I am looking for more power with a setup that will last over the years. I don't beat the crap out of that bike, and I won't even with more power.

Nevadasun

A set of S&S 4 1/8" bore cylinders, would have you at 117".
Easy to have those marking well over 130 ft/lbs, with small(er) cams, and medium compression ratios.
Scott
